Developing a tiny ecommerce site using microframework Slim

Last elections, I stepped forward as a volunteer for the Dutch Pirateparty.

They were struggling with Drupal, and the most pressing issue was getting a webshop going, using the Dutch Payment system iDeal, to take care of new member subscriptions.

I had quite some experience with Drupal e-commerce, and the default Dutch payment-method iDeal, in Drupal. Yet decided to build something from scratch instead, here is a short introduction, some reasoning and then how I build the shop.

Reasoning

Managing the Drupalproject was hard as it was.

Three people were already working, around the clock, at that time, to get the Drupalsite running and bug-free: theming, organic-groups-integration and LDAP-integration (centralising the login), amongst the daily "we need this and that page, if possible, ready before yesterday).

Adding a fourth track, integrating e-commerce, was just too much juggling and managing. And granting access to their codebase and server for just about everyone who wanted to help was not an option; so all commits would have to go via already overloaded other volunteers.

Making, and deploying this as standalone application, was a good option.

Drupals' (complete) lack of decent E-commerce options.

Yes, there is Commerce now. But in Juli, when all this was happening, it was simply not ready, for example, there was no stable iDeal payment and building one (against a still not stable payment-layer) was just too much work. But even now, I have great doubts about Commerces' set-up, architectures and concepts. Too much layers, too much in-browser configuration and overly complicated juggling of several tens of modules. I guess that is partly my aversion against this overly complicated drupal-configuring-by-clicking-together stuff, but it might also be because Drupal, as a CMS, will simply never have the focus and targeted development that any of the bazillion e-commerce alternatives have.

And Übercart has actually never been a serious option to me.

Integrating and developing the iDeal part for payment-module, was going to be much more work then building from scratch anyway.

Easy for new volunteers.

Drupal is becoming harder and harder to jump into and start developing, with each release; this site was Drupal 7 and I found that a lot of volunteers had trouble solving trivial issues in this Drupalsite. I am not talking about installing the eighty-fifth module, or configuring another view and entity. I am talking theming, bugfixing and module-development.

One of the things I did was helping with many such trivial issues like organising the menu's, side blocks, organic-groups setup and so on. There already was a shortage of people who knew enough of Drupal to help. There was no shortage of people who knew some CSS and HTML, though, yet getting them up-to-speed to employ these skills in Drupal theming and configuration proved too much work. I learned (again) how hard and difficult Drupal is, even for experienced (web)developers.

Also, the concept of this "become a member" thing was very much unstable: no one knew exactly what was needed, required and such. If you asked four people about what was required, you'd get four different (and even contradicting) answers. So I decided we needed the most agile system possible. Something that could have a new release several times a day, something that anyone with basic webdevelopment-skills could help fix or improve.

Slim

Hence PHP, hence Slim, and managed and deployed with git deploy.

Requirements, documentation and functional designs (wireframes)

Before I started coding I wrote down some guidelines made a few mockups and created the most basic requirement-doc possible.

The set-up

The code consists of a few directories and a very few files.

 Slim        # Contains the Slim Framework Library (classes)
 templates   # Contains snippets and PHP-files to render the actual HTML
 config.inc  # A few settings and globals
 ideal.inc   # Class/lib to handle the payment processor
 index.php   # The actual application
 secrets.inc # file which is excluded from the public git and from the docroot.

Template

The template was generated from the existing Drupalsite, by saving the page with Firefox (wget will not save CSS and such), parsing that trough tidy, and then manually clean up the rest of the HTML.

This turned out to be, by far, the most work and resulted in two extra directories "CSS" and "JS". The biggest problem was Drupal's extremely convoluted HTML, with nested divs twenty(levels) deep at some points.

In the end we learned that making the HTML, CSS and JavaScript from scratch would not only have saved us many hours, it would have left us with a far easier to maintain application.

The initial idea to keep as close to Drupal's output as possible. Since that would allow us to transfer changes in design to this subsite too, was not practical.

The application

The entire application lives in index.php.

In a Slim application, you set up routes that react to a HTTP-request, do stuff, and then return other stuff. Like so

$app->get('/', function () use ($app) {
  $app->render('_head.inc');
  $app->render(
    'landing.php',
    array(
      'default_amount' => DEFAULT_AMOUNT,
      'actions' => get_actions(),
    )
  );
  $app->render('_footer.inc');
  });

This is a PHP5 syntax, where you can create The above does the following:

  1. register a path, "/" with the HTTP-verb GET.
  2. Add an anonymous function to that; which will be executed when "/" is requested. PHP5 supports anonymous functions, closures.
  3. When the function is executed, we call render to tell what files under "/templates/" to render. We do this for head.inc and footer.inc.
  4. The template landing.php is rendered, but gets two variables passed along, which can then be printed in landing.php. Note the "Bug" where we don't actually print the actions? This part has been rewritten so often that things got messed up a little.

This is all code needed to create a page, with a form.

When you post this form, a slightly more complex function is called, the simplified version of that is:

$app->post('/pirate', function () use ($app) {
  $pirate = $app->request()->params();
  //... more preparing of the $pirate that will be stored in the database

  if (!valid($app,'email', FALSE, '/.+@.+\..+/', 'E-mailadres is niet correct')) {
    //...Lots of other validations of all the fields.
    $app->redirect("/");
  }

  $pirate = write_pirate($pirate);
  write_mail($pirate);

  $ideal = new Ideal(MERCHANT_ID, SUB_ID, HASH_KEY, AQUIRER_URL);
  //... Preparing a hidden form for payment

  $app->render('_head.inc');
  $app->render(
    'pirate.php',
    array(
      'hidden_form' => $ideal->hidden_form(),
      'url' => $ideal->aquirer_url,
    )
  );
  $app->render('_footer.inc');
  });

The values you posted are validated, then written to the database, and placed in a mail.

A new page is then rendered, with a hidden-form which will be posted to the payment-system.

iDeal

We have the simplest form of iDeal payment, iDeal lite. This is an offsite-payment, where you simply create a form with hidden values and POST that to the offsite payment-system. They then parse the POSTed values and present the customer with a payment-workflow.

On success, the customer might return to /success on error, there is a chance they end on /error. Because this is by no means a confirmation, we simply render a success or error page there; but take no actions.

$app->get('/error', function () use ($app) {
 $app->render('_head.inc');
 $app->render(
    'error.php'
  );
  $app->render('_footer.inc');
});

Other ideal-versions have a Post-back system, where their server confirms the payment; one of the earlier version of this application had that, since we did not know exactly what iDeal-version we'd go with. A confirm would be really simple to implement here:

$app->post('/confirm', function () use ($app) {
  $payment = $app->request()->params();
  $db = get_connection();
  $stmt = $db->prepare("UPDATE pirates SET status = :status WHERE id =
  :id");
  $stmt->bindParam("status", $payment["paymentStatus"]);
  $stmt->bindParam("pirate_id", $payment["purchaseID"]);
  $stmt->execute();
});

Obviously, in reality you'd probably need to parse the $payment to extract the correct information (the status and the user whose payment it was) from there. But again: you can see how extremely simple it is to implement.

Deploying

Since everything is stored in code, we can deploy really simple, using a git-push. Everyone with write access to the codebase can push changes there.

This allows for really fast rolling releases. Unfortunately, this breaks when someone hacks the code online. And with so many people, under such large pressure, that will happen. So all the time saved by having deployments under our fingertips with git, was undone by merging in changes that were not pushed correctly.

The solution to this is to make it easier and simpler to deploy The Right Way, then to hack something on a live server. (And not, as some might say, to make it harder to do the wrong thing; like removing Vim on the server or disallowing access to the files on the server).

I assumed git-deploy would be this easy, but apparently people under stress grabbed The Vim over SSH and hacked away on production code anyway. Apparently the git-route was not simple enough.

Conclusion

Several nights of coding, about 20 hours, of which 12 hours were CSS- and HTML-cleaning and fiddling, we made a really simple login-system.

The system was simple enough for others to start hacking on, in mere minutes.

And its result was simple, stable and friendly enough to handle the subscriptions of over 1100 in less then a month time.

Another example of what I call the "seeping trough of the complicated underlying technology". In order to keep a project and its result clean, simple and friendly, make sure the technology you use is simple, friendly and clean; KISS. Despite all the unstructured and rushed development, this application still works, is reasonable clean and can be revived and improved in mere minutes.

Something I doubt would have been possible with a large stack of e-commerce modules in Drupal; or hacked into a Magento or other shop; let alone built with Zend, Rails or Whatever other framework.

Woodcut from Doré. Purely illustrative
Doré Woodcut. Its only function is to make the layout look better. And these images are really nice themselves

About the author: Bèr Kessels is an experienced webdeveloper with a great passion for technology and Open Source. A golden combination to implement that technology in a good and efficient way. Follow @berkes on Twitter. Or read more about Bèr.
